115hp Yamaha Outboard
Download Fact Sheet
Technical Specifications
Dimensions
- Overall length
- EHT: 1554 mm, ET:826 mm
- Overall width
- 524 mm
- Steering angle
- 35 degrees each direction
- Overall height
- L: 1629 mm, X: 1756 mm
- Engine transom height
- L: 516 mm, X: 643 mm
- Dry weight
- 175 kg - 185 kg
Engine
- Ignition / advance system
- TCI
- Engine oil capacity
- 3.2 L / 3.0 L (with / without oil lter replacement)
- Compression ratio
- 10.0 : 1
- Alternator
- 35 A (battery charging: 27 A)
- Lubrication system
- Wet sump
- Bore x stroke
- 81.0 × 88.9 mm
- Engine type
- 16-Valve, DOHC, In-line 4 cylinders
- Displacement
- 1832 cm³
- Fuel induction system
- Fuel injection
