2.5hp Yamaha Outboard
Download Fact Sheet
Technical Specifications
Dimensions
- Overall length
- 625 mm
- Overall width
- 363 mm
- Steering angle
- 360 degree full pivot
- Overall height
- S: 1028 mm, L: 1155 mm
- Engine transom height
- S: 433 mm, L: 560 mm
- Dry weight
- S: 17 kg, L: 18 kg
Engine
- Ignition / advance system
- CDI
- Engine oil capacity
- 0.25 L
- Compression ratio
- 8.8 : 1
- Alternator
- Not available
- Lubrication system
- Splash lubrication
- Bore x stroke
- 54.0 × 31.5 mm
- Engine type
- OHV, 1-cylinder
- Displacement
- 72 cm³
- Fuel induction system
- 1 carburetor
