Yamaha 25HP Outboard

£3492

Built tough from double-walled polyethylene — low maintenance, safe, and ready for work or play.

Order direct with Flood Marine → Build a package →

Yamaha 25HP Outboard

25hp Yamaha Outboard
Download Fact Sheet
25hp Yamaha outboard engine

Technical Specifications

Dimensions

Overall length MH, WH, WHP: 1130 mm, WHT, WHD: 1129 mm
Overall width 378 mm
Steering angle4 5 degrees each direction
Overall heightS: 1106 mm, L: 1233 mm, X: 1320 mm
Dry weight 56 kg - 70 kg

Engine

Ignition / advance systemTCI
Engine oil capacity1.1 L / 1.0 L (with / without oil lter replacement)
Compression ratio9.1 : 1
Alternator16 A
Lubrication systemWet sump
Bore x stroke65.0 × 65.1 mm
Engine typeSOHC, In-line 2 cylinders
Displacement432 cm³
Fuel induction systemFuel injection
